45 Gallon, 2 Shelves, Manual Close Doors, Outdoor Flammable Storage Cabinet, Yellow - 814500

Model No
814500
$1,728.00

Usually ships in 20 business days

Warranty icon

Made in USA

Compliance OSHA Compliance Complies with International Fire Code Complies with NFPA Code 30
Approvals FM Approval

Product Summary

  • Fully spot welded Galvanneal 18 Gauge Steel double wall construction has 16 times more corrosion resistance than regular steel
  • Slanted top with rain gutter guides rain or snow away from the cabinet opening
  • Continuous stainless steel piano hinges ensure doors close smoothly and reliably
  • Stainless steel paddle handle lock with three-point latching system keeps contents secure
  • 12 Gauge skid allow easy relocation with forklifts
  • Extra hem on door for seal protection keeps rainwater from getting inside the cabinet
  • Stable trapezoid legs ensure stability on outdoor terrain
  • FM Approved
WARNING: This product can expose you to chemicals including lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

Description

In the complex landscape of industrial safety, the proper storage of hazardous and flammable liquids both indoors and outdoors is imperative. The Justrite yellow 45 Gallon Outdoor Flammable Storage Cabinet with Manual Close Doors, model 814500, is engineered specifically to mitigate the substantial risks associated with the improper handling and storage of these materials while outside.

Fully spot welded Galvanneal 18 Gauge Steel construction makes the cabinet highly resistant to corrosion - up to 16 times more than regular steel. This ensures a rust-resistant exterior capable of withstanding outdoor conditions. It also includes a slanted roof design to divert rain and snow away from the cabinet doors, protecting the contents from moisture. For ease of placement and mobility, even in challenging terrains, the cabinet is supported by 12 Gauge skids to easily move with a forklift, and bolstered with stable trapezoid legs.

The outdoor storage cabinet’s doors are uniquely designed for safety and security. Its patented self-indexing doors feature continuous stainless steel hinges to ensure a tight, sequential closure from top to bottom, reinforced with a three-point stainless steel self-latching bullet system for increased heat resistance and fail-safe operation. Additionally, the self-latching doors are easy to close and secure without the need for manual rotation, thanks to the stainless steel paddle latch U-Loc™ handle. To prevent unauthorized access, the doors can be locked with the included double key set or using a padlock (not included) via the U-Loc™ stainless steel paddle latch handle.

Other standard features on all Justrite flammable cabinets include:

  • Sturdy double wall construction with 1½-inch insulating air space
  • Patented SpillSlope® shelves direct spills to the back and bottom of the leakproof sump; welded shelf hangers interlock with the shelf to offer maximum stability with no flimsy brackets to lose. Adjustable on 3 in. centers, the shelves meet ANSI standards with a 350lb. (159-kg) safe allowable load.
  • 2-inch leakproof sump contains spills and leaks within the cabinet and meets EPA requirements
  • UV and chemical-resistant powder coated paint inside and out retains a high-gloss look and minimizes the effects of corrosion and humidity
  • Strategically placed dual vents with built in flash arresters work together to stop flames from entering the cabinet while preventing the build-up of vapors
  • Reflective HazAlert™ label provides a warning in English, Spanish and French to enhance visibility in low-light situations
  • Self-leveling feet help the cabinet adjust and balance on uneven surfaces
  • Built-in grounding connector makes grounding easy and mitigates the risk of static discharge

The cabinet exterior dimensions are 43 inches W x 18 inches D x 65 inches H; interior dimensions measure 39.5 inches W x 14.562 inches D x 60 inches H. Maximum flammable liquid capacity is 45 gallons. Model 814500 meets OSHA and NFPA requirements; FM approved.

Why Choose Justrite Outdoor Flammable Storage Cabinets?

Improperly stored flammable liquids are a significant contributor to industrial fires, even in outdoor settings. Justrite Outdoor Flammable Storage Cabinet offers a robust solution that allows for safe and economical storage of larger quantities of flammable, combustible, and corrosive chemicals outdoors, away from occupied buildings, while significantly reducing the risk of fires and explosions.

Open storage of hazardous chemicals also poses threats to the environment through potential spills or leaks, leading to soil and groundwater contamination. The cabinet's design includes features that prevent such outcomes, ensuring compliance with environmental regulations and safeguarding public health and the surrounding ecosystem.

A fire caused by hazardous chemicals can bury your business in direct and indirect costs, from property and inventory damage to business interruption, emergency response, and legal fees. Some businesses would not be able to recover from a case like this. By investing in Justrite outdoor flammable storage cabinets, you're not only enhancing safety but also protecting your business from potential financial disaster.

For self-closing doors, see model 814520.

Need indoor flammable cabinets? View our complete line of 45-gallon flammable cabinets

Specifications

More Information
Model No 814500
Badge New
UPC 697841272309
International Model No. 814500
Color Yellow
Material Specifications 18-Gauge Steel
FM Approval Yes
OSHA Compliance Yes
Complies with International Fire Code Yes
Complies with NFPA Code 30 Yes
Complies with NFPA 1 Fire-Code Yes
Storage Type Vertical
Capacity 45 gallon
Liter Capacity 113.56
Number of Doors 2
Door Type Manual
Number of Shelves 2
Adjustable Shelves Yes
Dimensions, Exterior 43"W x 18"D x 65"H
1092W x 457D x 1651H
Dimensions, Interior 39.5"W x 14.562"D x 60"H
1003W x 370D x 1537H
Height (Inches) 65
Width (Inches) 43
Depth 18
Net Weight, lbs 264.7
Net Weight, kg 120.0

Discover the durability of Justrite outdoor flammable safety cabinets, meticulously engineered to withstand the harshest outdoor conditions and potential impact.

New Outdoor Cabinet Features

Sturdy Construction

Fully spot welded Galvanneal 18-gauge steel construction provides 16 times more resistance against corrosives than regular steel, creating a rust-resistant cabinet



Weather Resistant

Slanted top with rain gutter guides rain or snow away from cabinet interior

Durable Door Hinges

Stainless steel continual piano hinges ensure reliable closure and even weight distribution, making it easier to open and close



Keep Contents Secure

Stainless steel paddle latch handle lock with three-point latching secures the contents



Stable Trapezoid Legs

Durable 12 gauge steel trapezoid legs feature an open design to accommodate forklifts as well as tools to adjust, mount or add accessories

Safe and Compliant

Meets OSHA and NFPA standards; FM Approved

Outdoor cabinets also include these standard features:

  • Patented SpillSlope® shelves with fully welded, leakproof sump
  • Ground screw
  • Durable, chemical-resistant powder coated paint
  • Resistance to UV
  • Vent with built-in flash arresters
  • Welded shelf hangers



Model Model Number UPC
30 Gallon Manual Close Doors 813000 697841272330
30 Gallon Self Close Doors 813020 697841272347
45 Gallon Manual Close Doors 814500  697841272309
45 Gallon Self Close Doors 814520  697841272316
60 Gallon Manual Close Doors  816000  697841272385
60 Gallon Self Close Doors  816020  697841272392
90 Gallon Manual Close Doors  819000  697841272408
90 Gallon Self Close Doors  819020  697841272415

Advantages of Galvanneal Steel

All Justrite outdoor cabinets are constructed of durable Galvanneal steel, which offers many advantages

  • Highly ductile: Easy to shape and weld
  • Corrosion resistance: Features a zinc-iron alloy coating that resists up to 16 times more corrosion than regular steel
  • Hard and resilient: More resistant to chipping and scratching
  • Ideal for painting: Surface roughness increases paint adhesion

Justrite Outdoor Flammable Safety Cabinets vs the Competition

Features Justrite Competition
Durable and chemical resistant powder coat paint
 Slanted top with rain gutter
 Stainless steel hinges
 Stainless steel paddle handled with 3-point latch
 Fork-liftable legs
 Full spot welded Galvanneal steel
 Vent with built-in flash arrestors
 Welded shelf hangers
 Leak proof sump
 Extra hem on door for seal protection

 View the Full Line of Safety Cabinets and Storage Products

Outdoor Flammable
Cabinets

View More >

Drum Storage
Cabinets

View More >

Paint Storage
Cabinets

View More >

Corrosive
Cabinets

View More >

Applications for Outdoor Flammable Storage Cabinets

Construction

Consolidate the storage of fuel, fuel additives, lubricants, and solvents into one secure area, mitigating fire risks by positioning them away from other operations. Using outdoor cabinets also reduces downtime by keeping necessary supplies close at hand for equipment refueling and maintenance.

Agriculture

Ideal to house petroleum-based lubricants and flammable products used for farm equipment, allowing storage to be situated near field operations. This accessibility saves time and the mobility of these cabinets supports a fleet as it moves across different fields.

Marinas / Boat Yards

Storage cabinets in marinas and boatyards contain spills with an integral sump, preventing water pollution and avoiding environmental fines, while keeping flammable materials like fuel handy for boat servicing.

Mining

Given mining's often remote and rugged environments, outdoor flammable cabinets facilitate safe storage and spill containment for fueling equipment, crucial in areas without utility access. Additionally, the portability of these cabinets ensures they can be relocated easily with a forklift as mining operations progress.

Military

Outdoor cabinets help securely store large quantities of flammable liquids needed for refueling and maintaining equipment, while offering robust protection from potential fire hazards in conflict zones or after accidents.

Petrochemical / Oil & Gas Industries

Outdoor flammable storage cabinets are essential for safe, organized outdoor storage of samples, additives, and equipment like pumps, safeguarding against fires and spills in remote operational areas.

Safety Cabinets with Self-Closing Doors – The Safest Option for Chemical Storage

Handling chemicals in the workplace can be a straightforward task with the right equipment. Justrite flammable safety cabinets with self-closing doors simplify this process remarkably.  Not only are the self-closing doors safer in case of fire, it’s also easier to work with the cabinet doors open.

No need to prop them with something heavy, just use the fusible link as it was meant to operate. Installation is easy. While holding the door open, the user inserts the fusible link, then releases the door slowly. The link catches behind the hinge, creating tension that allows the door to remain open.

How to Use Fusible Links to Prop Cabinet Doors Open

Why Use Safety Cabinets with Self-Closing Doors?

Safest Option for Chemical Point of Use in the Workplace.

The fail-safe closing mechanism ensures three-point stainless steel bullet latching system works every time, removing the “human” element. The hidden self-closing feature ensures unobstructed access to the top shelf space, and the self-indexing doors ensure they close in the correct order, achieving a secure seal from top to bottom.

Keep Doors Open When Working with Chemicals

The self-closing doors are designed to automatically close, so when working out of the cabinet in the workplace, use the fusible link to prop doors open. If inadvertently left open in case of fire, the link will melt at 165 degrees F, slamming the doors shut to prevent fire from reaching the cabinet contents.

Meets All Fire Codes

Some states require using safety cabinets with self-closing doors, but not all of them. Since fire codes and regulations can vary by state, choosing a cabinet with self-closing doors is the only way to guarantee compliance with NFPA and IFC codes as well as authorities having jurisdiction.

New Fusible Link Mounting Location 1 (1).pdf

Access the Safety Your Workplace Needs

Buying safety products should be easy, but determining which products to use and where to find them can be frustrating.  Justrite takes the hassle out of the process with a comprehensive portfolio of safety equipment. Find out what other products can help protect your people, property and the planet.
