Gas Cylinder Pallet With Firewall, 21 Cylinder Capacity, with Ramp, Steel - 35220

Model No
35220
$1,448.00

Made in USA

Usually ships in 20 days Please contact customer service at
800-798-9250 for lead times.

Need a bulk or special order? Get a quote

Compliance OSHA Compliance

Product Summary

  • Fully enclosed 7.75-in wide (197-mm) forklift channels with two way access
  • Textured finish on the pallet provides a non-skid surface

Description

Transport multiple gas cylinders securely with a forklift using these end-load oriented pallets. Secure a group of gas cylinders using the 10,000-lb (4,536-kg) DOT compliant strap that attaches to frame at either 12-, 24- or 36-in (305-, 610- or 915-mm) from the deck. Fully welded construction from 11-gauge (3-mm) hot-rolled steel and structural tube steel, powder-coated to ensure longevity and chemical resistance. For easier loading and unloading, the pallets includes a 16-in (406-mm) hinged ramp. Once loaded, ramp lifts up to lie flat against unit for compact storage. Helps comply with OSHA, NFP1, NFPA 55, and CGA.

Specifications

More Information
Model No 35220
UPC 697841210738
Cylinder Capacity Varies
Cylinder Capacity with Max Cylinder Dia (21) 9 inch, (12) 12 inch, or (4) 21 inch
Ramp Equipped Yes
Mount Type Forklift
Weight Capacity (lb) 6000
Weight Capacity (kg) 2722
Strap Style Ratchet Binding
Straps Per Cylinder 1 Total
Material Specifications Steel
Complies with NFPA 1 Fire-Code Yes
NFPA 55 Yes
OSHA Compliance Yes
CGA Yes
Net Weight, lbs 310
Net Weight, kg 141
Net Dimensions (W x D x H) 48 x 66 x 38 inches
1219 x 1676 x 965 mm
