Hughes Handheld Drench Hose, Wall Mount, (1) In-Line Nozzle
Hughes Handheld Drench Hose, Wall Mount, (1) In-Line Nozzle
Hughes Handheld Drench Hose, Wall Mount, (1) In-Line Nozzle
Wall mounted handheld drench hose features an in-line single nozzle for hazardous environments where there is a risk of small spillages of chemicals or dangerous substances. Includes an inspection record tag for recording test and service history.
Wall mounted handheld drench hose features an in-line single nozzle for hazardous environments where there is a risk of small spillages of chemicals or dangerous substances. Includes an inspection record tag for recording test and service history.
| Model No. | OPT100 |
|---|---|
| Net Weight, lbs | 2.2 |
| Net Weight, kg | 1 |
| Dimensions, Exterior | 10.8" H x 2.7" W x 2.7" D |
| 274mm H x 69mm W x 69mm D | |
| Water Inlet Size NPT | 1/2 in (F) - Hose |
| Minimum Operating Pressure | 1.5 bar g, 22 PSI |
| Maximum Operating Pressure | 6 bar g, 87 PSI |
| Water Flow Eye/Face Liters/min | 8 |
| Water Flow Eye/Face US Gal/min | 2.11 |
| Operating Valve Material | Non-return |
| Mounting Type | Wall |
| Color/Finish | White, Green, Red |
| Activation Method | Squeeze grip operated with lock-on actuating button |
| Minimum Ambient Temperature, °F | 41 |
| Minimum Ambient Temperature, °C | 5 |
| Maximum Ambient Temperature, °F | 95 |
| Maximum Ambient Temperature, °C | 35 |
Write Your Own Review
MODEL NO: OPT100
Key Benefits
- Fitted with pop-off dust cover, a non-return valve and flow regulator
- Complete with 4.9-feet (1.5-m) of reinforced hose, particularly useful for treating disabled personnel
- Lock-on actuating button for ease of use
Specification
| Model No. | OPT100 |
|---|---|
| Net Weight, lbs | 2.2 |
| Net Weight, kg | 1 |
| Dimensions, Exterior | 10.8" H x 2.7" W x 2.7" D |
| 274mm H x 69mm W x 69mm D | |
| Water Inlet Size NPT | 1/2 in (F) - Hose |
| Minimum Operating Pressure | 1.5 bar g, 22 PSI |
| Maximum Operating Pressure | 6 bar g, 87 PSI |
| Water Flow Eye/Face Liters/min | 8 |
| Water Flow Eye/Face US Gal/min | 2.11 |
| Operating Valve Material | Non-return |
| Mounting Type | Wall |
| Color/Finish | White, Green, Red |
| Activation Method | Squeeze grip operated with lock-on actuating button |
| Minimum Ambient Temperature, °F | 41 |
| Minimum Ambient Temperature, °C | 5 |
| Maximum Ambient Temperature, °F | 95 |
| Maximum Ambient Temperature, °C | 35 |
